DUAL PLATE CHECK VALVE


Dual plate check valve is a type of non-return valve allowing flow in one direction.

It consists of two spring loaded semi circular plate and has compact, lightweight and low-pressure-drop design. While it is mostly used in engine secondary airflow systems.

Long cyclic life and maintenance free design allows it to operate in commercial and military engines and subsystems.


TECHNICAL SPECIFICATIONS

Cracking Pressure: 0.07 bar
Proof Pressure: 42 bar
Operating Pressure: Up to 3 bar

Operating Temperature: 400°C
Body Material: Stainless Steel
Cyclic Life: More than 10^6
